SPECIFICATIONS

Engine / Drive Train

Engine: 177.3cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 12.06HP/7000-7500RPM

Max Torque: 9.74ft-lb/6000RPM

Bore × Stroke: 62.5mm x 58mm

Compression Ratio: 9.6:1

Cooling System: Air cooled

Transmission: Fully automatic with reverse

Start System: Electric start

Ignition: CDI

Final Drive: Dual Chain drive (double chain)

Max Speed: 40MPH

Battery: 12V9Ah

Frame / Body / Suspension / Brakes

Front Suspension: Dual A-Arm with dual shock absorbers.

Rear Suspension: Swing arm with dual shock absorbers.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake.

Front Tires: 23x7-10

Rear Tires: 22x10-10

(New Alloy Rim)

Capacities / Dimensions

Max Load: 396.9lbs

Gross Weight: 771.75lbs

Net Weight: 639.45lbs

Overall Length: 98.43inches

Overall Width: 59.06inches

Overall Height: 57.88inches

Carton Dimensions (L × W × H): 91.34x49.4x31.10inches

Seat Height: 16.54inches

Wheelbase: 78.7inches

Ground Clearance: 11.81inches

Gas Tank Capacity: 3.96gal

Fuel Consumption: 60.47mpg
