SPECIFICATIONS

Motor

Motor Type: Brush Motor Chain Driver

Max Output: 1000W

Max Speed: 24km/h

Three Speed Switch: Available Low-Medium-High

Battery: 36V15Ah Maintenance-Free AGM Battery

Transmission: CHAIN; Forward-Neutral-Reverse

Suspension/ Wheels/Brakes‍ ‍

Front/Rear Suspension: F:14* 4.10-6, R: 14*5.00-6

Front Shock Absorber: Spring Shock

Rear Shock Absorber: Spring Hydraulic Shock

Brakes Front: Mechanical Disk Brake

Brakes Rear: Mechanical Disk Brake

Dimensions and Weight

Overall Vehicle (L X W X H): 1190mm X 705mm X 765mm

Wheel Base: 700mm

Front Tread: 590mm

Rear Tread: 450mm

Seat Height: 540mm

Gross Vehicle Weight 136lbs/61.5kg

Container Loading 80PCS/20FT, 200PCS/40HQ
