SPECIFICATIONS:

Engine / Drive Train

Engine: 275.8cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 17.43HP/6500RPM

Max Torque: 16.23ft-lb/6000RPM

Bore × Stroke: 72mm x 67mm

Compression Ratio: 10.0:1

Cooling System: Water cooled

Transmission: Fully automatic with reverse

Start System: Electric start

Ignition: EFI

Final Drive: Chain drive

Max Speed: 50MPH

Battery: 12V14Ah

Frame / Body / Suspension / Brakes

Front Suspension: Dual A-Arm with dual shock absorbers.

Rear Suspension: Swing arm with dual shock absorbers.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake.

Front Tires: 23x7-10 Alloy Rim

Rear Tires: 22x10-10 Alloy Rim

Capacities / Dimensions

Max Load: 650lbs

Gross Weight: 950lbs

Net Weight: 805lbs

Overall Length: 118.11inches

Overall Width: 68.9inches

Overall Height: 70.9inches

Carton Dimensions (L × W × H): 117x45.3x25.2inches

Seat Height: 21.66inches

Wheelbase: 98.43inches

Ground Clearance: 7.88inches

Gas Tank Capacity: 3.96gal

Fuel Consumption: 42.22mpg
