SPECIFICATIONS:

ENGINE INFO

Engine type 4 stroke

Displacement 229cc

Cooling Air cooling

Max horsepower 11.5 Kw/7500

Max torque 17.0 N.m/5500

Bore*stroke 67*65

Max speed 105km/h

Ignition CDI

Starting system Electric&kick

Battery 12V9Ah

Engine oil 1.1L

CHASSIS ETC.

Drive Chain

Suspension,Front/Rear Double shocks

Brakes,Front/Rear "Front Disc Brake

Rear Drum Brake"

Tires,Front/Rear 90/80-17 / 90/80-17

Fuel Capacity 12.8 L

Weight,G.W./N.W. 135KG / 115KG

DIMENSIONS

Wheelbase 1270 mm

OA L*W*H 1850×920×1030 mm

Seat Height 780mm

Shipping info 40’HQ 105 units
