Specifications

Engine

Transmission: Automatic H-L-N-R-P

Horsepower: 26 HP

Cooling: Liquid

Drivetrain: Shaft Drive; On-Demand 2WD/4WD; Locking Differential

Ignition: Electronic Control Unit

Fuel System: EFI

Compression Ratio: 10 : 1

Bore & Stroke: 82 mm x 74 mm

Displacement: 391 cc

Engine Type: Four-Stroke, Single Cylinder

Fuel Tank Capacity: 4.8 gallons

Battery: 12V; 30Ah

Dimensions

Bed Capacity: 250 lbs

Dry Weight: 1102 lbs

Front Tires: 25 x 8-12

Ground Clearance: 9 in

Length x Width x Height: 122 in x 56.5 in x 74.5 in

Load Capacity: 600 lbs

Rear Tires: 25 x 10-12

Seat Height: 34.5 in

Towing Capacity: 1000 lbs

Wheelbase: 74 in

Suspension

Front Suspension: McPherson Independent

Rear Suspension: Independent Double A-Arm

Brakes

Front Brake: Dual Ventilated Hydraulic Disc

Rear Brake: Dual Ventilated Hydraulic Disc
