SPECIFICATIONS

ENGINE

Engine Make / Type Air-Cooled SOHC 4-Stroke 176cc

Top Speed 35MPH

Lubrication Type Pressure and Hybrid Splash Lubrication

Max Torque 10N·m/6000r/min

Compression Ratio 9.5:1

Valve Configuration 2 Valve

TRANSMISSION & DRIVE

Drive Type Fully Automatic

Gears CVT – F,N,R

Clutching Type Automatic Centrifugal Dry

Drive line Type Chain

Starting System Electric Start

SUSPENSION

Front Suspension Single A-Arm

Rear Suspension Rear Single Shaft Swing Arm

BRAKES, TIRES & WHEELS

Front/Rear Brakes Disc Brakes

Front Tire 20×7-10

Rear Tire 19×10-9

Front/Rear Tread 820mm / 810mm

MEASUREMENTS & DIMENSIONS

ATV Dimensions 63'(L) x 41'(W) x 41'(H)

Ground Clearance 5.9in

Wheelbase 45in
