TECHNICAL SPECIFICATION

ENGINE TYPE: SINGLE CYLINDER、250cc air cooler 2 valves、4-STROKE

L×W×H: 1625*1060*1065

WHEELBASE: 1090±20mm

MINIMUM GROUND CLEARANCE: 135±15mm

SEAT HEIGHT: 790±15 mm

MINIMUM TURNING CIRCLE DIAMETER: 5900±500mm

RATED LOAD: 150kg

NET WEIGHT: 149kg

F&R BRAKE: F&R HYDRAULIC DISC

F&R TIRE: AT20*7.0-10/AT19*10-9

FUEL TANK: 9L

BATTERY: 12V/7HA

MAXIMUM SPEED: 70km/h

COMPRESSION RATIO: 9.0:1

MAX.POWER: 12（1±5%）kW /7500（1±5%）rpm

MAX.TORQUE: 17（1±5%）N · m/6000（1±5%）rpm

CLUTCH METHOD: Manual

**The images shown are for illustration purposes only and may not be an exact representation of the product.
