SPECIFICATIONS:

• Electric/Pull Start

• Tow Hitch

• Oil-Cooler

Engine / Drive Train

Engine: 177.3cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 12.06HP/7000-7500RPM

Max Torque: 9.74ft-lb/6000RPM

Bore × Stroke: 62.5mm x 58mm

Compression Ratio: 9.6:1

Cooling System:  Air cooled

Transmission:  Fully automatic with reverse

Start System:  Electric start and recoil pull start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 45MPH

Battery: 12V9Ah

Frame / Body / Suspension / Brakes

Front Suspension:  Dual A-Arm with dual shock absorbers.

Rear Suspension:  Swing arm with dual shock absorbers.

Front Brake: Hydraulic disc brake.

Rear Brake:  Hydraulic disc brake.

Front Tires: 21x7-10

Rear Tires: 22x10-10

Capacities / Dimensions

Max Load: 396.9lbs

Gross Weight: 639.45lbs

Net Weight: 584.33lbs

Overall Length: 95.67inches

Overall Width: 59.06inches

Overall Height: 60.63inches

Carton Dimensions (L × W × H):  90.56x51.58x23.63inches

Wheelbase: 74.02inches

Ground Clearance: 8.66inches

Gas Tank Capacity: 3.96gal

Fuel Consumption: 65.34mpg
