SPECIFICATIONS:

Engine / Drive Train

Engine: 140cc, 4-stroke

Cylinder Arrangement: Single cylinder

Max Horsepower: 9.39HP/7500RPM

Max Torque: 7ft-lb/5500RPM

Bore × Stroke: 56.5mmx55.5inches

Compression Ratio: 9.4:1

Cooling System: Air cooled

Transmission: 2-speed (fully automatic) with reverse

Start System: Electric start

Ignition: CDI

Final Drive: Chain drive

Max Speed: 35MPH

Battery: 12V5Ah

Frame / Body / Suspension / Brakes

Front Suspension: Dual A-Arm with dual shock absorbers.

Rear Suspension: Swing arm with dual shock absorbers.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake.

Front Tires: 19x7-8

Rear Tires: 18x9.5-8

Capacities / Dimensions

Max Load: 330.75lbs

Gross Weight: 452lbs

Net Weight: 396.9lbs

Overall Length: 79.52inches

Overall Width: 48.03inches

Overall Height: 59.06inches

Carton Dimensions (L × W × H): 77.56x45.28x22.84inches

Seat Height: 11.81inches

Wheelbase: 63.78inches

Ground Clearance: 3.94inches

Gas Tank Capacity: 2.11gal

Fuel Consumption: 78.4mpg
