SPECIFICATIONS:

Length X width X height 80.7" X 27.9" X 41.7"

Wheelbase 56.7"

Curb weight 309 LBS

Rated load 474 LBS

Max. speed 75 mph

Brake type （ Front / Rear ） DISC

Brake Operating （ Front / Rear ） HANDS BRAKE

Wheel Rim （ Front / Rear ) 3.0*17 / 4.0*17

Tire size （ Front / Rear ） 110/70-17 / 140/70-17

Engine Engine Model No. ZS165FMM-L

Make ZONG SHEN

Identification / Type Single Cyliner,Oil-cooling with Balancer

Bore × Stroke mm 65.5×66.2

Engine capacity cc 250

Compression Ratio 9.2:1

Max. Power kW/(r/min) 12kW/7500r/min

Max. Torque N · m/(r/min) 18Nm/5500r/min

Mini. Idle Speed r/min 1600r/min±100

Lubrication Forced lubrication

Lubricant Type SJ10W/40

Clutch Type Oil-bathing multi-plate clutch

Starting Electronic

Ignition EFI
